Product Overview
The Length Counter Unit is an essential inline accessory for measuring the precise length of cables, wires, and rewinding. With a digital or mechanical counter, this unit ensures accurate metering and supports auto-stop, alarm, or printing functions based on preset lengths. Its compact design, high-speed capability, and compatibility with various line setups make it a critical component for quality control and production efficiency.
Key Features
- High Accuracy Measurement
Ensures consistent length recording with digital or mechanical precision. - Digital Counter Options
Available with preset-table alarms, auto-stop, and production data logging. - Smooth Material Handling
Ceramic coated wheels prevent damage to soft wires, hoses, or tubes. - Maintenance-Free Design
No motor required for basic models; minimal wear-and-tear. - Easy Installation
Compact footprint and flexible mounting options for quick integration. - Inline Synchronization
Can be linked to cutters, coilers, printers, or PLC systems.
Optional Add-Ons
- Adjustable guide rollers for multi-size cables
- Encoder feedback to PLC for automated control
Applications
Perfect for cable plants and hose, wires
Technical Specifications
Specification | Details |
Model | LC-100 / LC-200 / LC-DIGI |
Application | Wire, Cable (Flexible Materials) |
Measuring Diameter Range | 1 mm – 25 mm (customizable rollers available) |
Measuring Accuracy | ±0.2% to ±0.5% |
Line Speed Capacity | Up to 400 m/min |
Counter Type | Mechanical / Digital / PLC-Linked |
Display Type | Analog Dial / LED / LCD Display |
Preset Functions | Auto Stop / Alarm / Output Relay for Cutter or Printer |
Encoder Resolution | Up to 1000 PPR (for digital versions) |
Drive Requirement | Free-running / Encoder Driven (No power for mechanical units) |
Mounting Options | Floor Stand / Table Mount / Inline Frame Integration |
Operating Temperature | 0°C to 50°C |
Structure Material | Mild Steel or Aluminum (Powder-Coated / Anodized) |
Dimensions (Approx.) | 450 x 300 x 350 mm |
Weight | 20 – 40 kg |
